Fail2Ban Demystified: Custom Fail2Ban Actions
October 1, 2024 - Reading time: 33 minutes |
Download PDF
Fail2Ban is a powerful security tool that bridges your public-facing network services (ssh, mail server, web server, etc.) and your firewall. The Fail2Ban daemon constantly monitors your server logs, looking for troublemakers. When an intruder or suspicious activity is detected, it takes action! By default, Fail2Ban writes a temporary firewall rule that blocks the offender’s IP address on selected ports for a short period of time.
The real power in Fail2Ban, though, lies in its customizability. Using custom action scripts, admins can configure how Fail2Ban responds to threats, extending its abilities far beyond simply interfacing with the firewall. For example, you can define actions that will send an email or notification, write to a log file or database, invoke a web API, react differently in different contexts, and so on. The possibilities are unlimited!
This article explains how actions in Fail2Ban are defined and customized so that you can get the most out of Fail2Ban.
Quick Links: If you're already familiar with Fail2Ban's actions and you're just looking for a list of valid actions or action tags, you can jump ahead to what you need:
Fail2Ban Conventions
If you’re not yet experienced with Fail2Ban configuration, it will be helpful for you to be familiar with these terms:
filter
A filter is a set of customized regular expressions and properties that is used to match threatening log entries. When a filter is matched, the actions in the corresponding jail are invoked. Filter definitions are normally found in the filter.d subdirectory. This article touches only briefly on filters, but a companion article will describe them in more detail.
action
An action is a shell command (or commands) that Fail2Ban executes at appropriate times. For example a ban action is executed when Fail2Ban invokes a ban against an IP address. Actions are normally defined by configuration files in the action.d subdirectory.
jail
A jail is a set of actions and parameters that Fail2Ban applies when its filter is matched. A jail can have multiple actions of the same type, but can only have one filter. Jails are normally defined in jail.conf and jail.local in the configuration directory, and by files in the jail.d subdirectory.
Action Configuration Files
This article assumes that you already have Fail2Ban installed and configured correctly to work with your firewall and now you want to start customizing what it does. The action configuration files are found in the action.d subdirectory of your Fail2Ban configuration directory. By default, this is /etc/fail2ban/action.d. In this directory, you’ll find a few default templates for sending email alerts, alerting AbuseIPDB.com or Blocklist.de, writing to hosts.deny, and a few other actions, but without further configuration, Fail2Ban only invokes the actions for writing (and unwriting) firewall rules.
By convention, all Fail2Ban configuration files end in .conf (for default templates provided with the Fail2Ban package) or .local (for user-defined configurations). When a configuration is parsed by Fail2Ban, it will first load the .conf file, and then load the corresponding .local file, updating any parameters that differ between the two files.
Important: Since .conf files may be overwritten by new versions when Fail2Ban is updated, you should not make any changes directly to these files. Instead, make a copy with the .local suffix and edit the copy:
$ sudo cp mail-whois.conf mail-whois.local
If you are only adding or changing a small number of parameters, it may be more efficient to just create a new .local file with those parameters:
$ echo dest=flathead@example.com | sudo tee mail-whois.local
Sections
Action configuration files can have up to three sections, identified by the name of the section in square brackets.
[INCLUDES]
Configuration files listed in this optional section will be parsed either before or after the current configuration file. This is useful for importing or updating common variables. Separate multiple files with spaces or include them on separate lines beginning with a space or tab.
before = file(s)
Parse these files before the current configuration file.
after = file(s)
Parse these files after the current configuration file, updating variables with new values.
In the following example, the parameters in mail-addresses.local and mail-options.local will be read, then those parameters will be updated and amended by the parameters in this file, then finally mail-overrides.local will be parsed.
[INCLUDES]
before = mail-addresses.local
mail-options.local
after = mail-overrides.local
[Definition]
This section defines the various actions that Fail2Ban will take, for example, when banning or unbanning an IP address. See the section Fail2Ban Actions below for details.
Note that you can specify that the actions for banning and unbanning should be ignored for restored bans (for example, bans that are restored when Fail2Ban is restarted) by including:
norestored = 1
[Init]
This optional section defines the default values for variables used by the actions in this configuration. The default values will be overridden when either:
- A new value is assigned in a configuration file parsed after this one in the [INCLUDES] section (see above), or
- A value is explicitly assigned in the jail definition.
For example,
[INCLUDES]
after = mail-overrides.local
[Definition]
norestored = 1
actionban = writelog.sh <message>
[Init]
message = An IP address has been banned
In this example, a shell script called “writelog.sh” is executed with the argument message when a scofflaw is banned. (Note the angle brackets around the variable name.) The default value for message is “An IP address has been banned” but if message is redefined by mail-overrides.local, or by the jail’s definition, the updated value will be used instead.
Fail2Ban Actions
These are the actions that can be included in the [Definition] section of an action configuration file. Each specifies a command or script to execute in a certain context. By default, the Fail2Ban daemon runs as root, but if you have changed that behavior, you’ll need to make sure the daemon’s user has permissions for the desired commands.
Action scripts can be multiple lines so long as each new line begins with a space or tab, similar to shell scripts.
Most custom actions will only need an actionban command or script. The list of valid actions includes:
actionban
As the name implies, Fail2Ban will try to run this command or script when it normally bans an IP address. If the command fails (returns an exit code other than 0), actioncheck will be run next, otherwise the ban is considered enforced. You can instruct Fail2Ban to ignore this action for restored bans by setting norestored=1 in the [Definition] section of the file.
actionunban
This defines the command or script that Fail2Ban will run when an IP address is unbanned, either because it has reached its expiration time or an unban has been forced, such as when the service is stopped. If the command fails (returns an exit code other than 0), actioncheck will run next. You can instruct Fail2Ban to ignore this action for restored bans by setting norestored=1 in the [Definition] section of the file.
actionprolong
This defines the command that Fail2Ban will run when it extends an IP’s ban time due to repeated offenses. This occurs when (1) the jail’s bantime.increment property is “true” and (2) there is at least one previous ban for this IP in the database. This action is run in addition to and after actionban has completed, which may be a few seconds later.
actioncheck
This command or script is invoked only if actionban or actionunban fails (returns an exit code other than 0). If actioncheck also returns an exit code other than 0, then actionrepair will be called next. For example, if actionban tries to write to a file but fails, actioncheck could verify the existence and permissions of the file, then, if it doesn’t exist, actionrepair could recreate the file and set permissions. Note that in early versions of Fail2Ban, actioncheck was called before each actionban, but this behavior was changed as of version 1.0.1.
actionrepair
This command or script is invoked only if actioncheck returns an error code other than 0.
actionreban
This command or script runs when a ban is reinstated after a daemon restart. If it does not exist, actionban runs instead.
actionstart
This command or script runs when a jail is started.
actionstop
This command or script runs when a jail is stopped.
actionflush
This command or script runs when several or all bans are removed in one fell swoop, such as when Fail2Ban is stopped or is reloaded with a previously-active jail removed, or with fail2ban-client unban –all. By default, actionunban is called for each banned IP.
Action Tags
Fail2Ban pre-defines several action tags with useful values. To use them in commands or scripts, enclose the variable name in angle brackets:
actionban = banomatic.sh <ip> <bancount>
will invoke the “banomatic.sh” script with the banned IP address and the number of times that IP address has been banned as arguments.
You can also use angle brackets to refer to variables defined within your configuration file.
These action tags are pre-defined:
| name | The name of the jail for this ban |
| fq-hostname | The fully-qualified hostname of your host (e.g. mail.example.com) |
| sh-hostname | The short hostname of your host (e.g. mail) |
| ip | The banned IP address |
| ip-rev | The IP address, in reversed order, suitable for reverse DNS lookups. For example, if <ip> is “111.222.333.444”, then <ip-rev> will be “444.333.222.111.” |
| ip-host | The banned IP’s hostname, if it has a PTR record (which it probably does not, in which case it defaults to “None”) |
| fid |
The failure ID. Defaults to the banned IP address unless it has been changed by the filter. This can be used to give an ID to general failures that do not include an IP address |
| family | The IP address family: INET4 or INET6 |
| time | The unix epoch time of the ban. If you use this, you’ll probably want to convert it to a human-readable format using the date shell command, for example date -d ‘@<time>’ |
| bancount | The total number of bans in the database for the IP address in this jail |
| jail.banned | The number of IP addresses currently banned for this jail |
| jail.banned_total | The total number of IP addresses banned for this jail since the last restart |
| bantime | The length of the ban, in seconds |
| failures | The number of times the filter matched a log line for this ban |
| ipjailfailures | The total number of filter matches in the database for this IP in this jail |
| ipfailures | The total number of filter matches in the database for this IP across all jails |
| jail.found | The current number of filter matches for this jail, for all IP addresses |
| jail.found_total | The total number of filter matches since restart for this jail for all IP addresses |
| matches | A list of the log lines that were matched for this ban |
| ipjailmatches | A list of all matches in the database for this IP address in this jail |
| ipmatches | A list of all matches in the database for this IP address across all jails |
| raw-ticket | An object containing data relevant to this ban, including ip, time, bantime, bancount, failures, and matches. |
| F-name | Custom tags that can be set in the filter regex. See below. |
| restored | 1 if the ban has been restored, for example after a daemon restart, or 0 otherwise. |
| br | A newline (“\n”) character |
| sp | A literal space (" ") character |
For cumulative historical values, such as bancount and ipjailmatches, the lookback period depends on the database’s retention length, which defaults to 1 day. The retention length is defined by the dbpurgeage property in fail2ban.conf. (Remember to copy the file to fail2ban.local if you make changes).
The “F-name” tags are custom tags that can be defined in a jail’s filter (in the filter configuration file in filter.d) by enclosing the desired pattern in a pair of <F-name>. . .</F-name> tags. For example, if the failregex includes this snippet at an appropriate place:
failregex = . . . <F-EMAIL>\w+@(\w+\.?)+</F-EMAIL> . . .
then the F-EMAIL variable will be pre-populated with the matching email address and can be used with <F-EMAIL> in actions. More details about custom filter tags will be discussed in another article about Fail2Ban filters.
Action scripts can also refer to variables, including variables that define scripts, using python-like format:
actionban = %(variable)s
The variable “known/parameter” is particularly useful. It is pre-defined as the last-known definition for an action or parameter and can be used to refer to an inherited definition.
For example, suppose you want to use the existing mail.conf configuration (which uses the “mail” command to send an email notification each time an IP is banned), but you only want to send the email when an IP has been banned at least three times. To do that, you could create a configuration file mail.local that looks like this:
# mail.local
# Send an email notification for three or more bans from
# the same IP
[Definition]
actionban = if [<bancount> -ge <toomany>]; then
%(known/actionban)s
fi
[Init]
toomany = 3
Linking Actions to Jails
The actions associated with each jail are defined in jail.local with the action property. You can add a new action to existing ones in the [DEFAULT] section or in individual jails. Each jail can have more than one action, with each one on a new line beginning with whitespace. When adding a new action, append it to any that already exist so you don’t override the existing firewall actions.
For example, if you want to add mail.local to a jail (or default) and it already has
action = %(action_)s
then add your action beneath it, not including the .local extension:
action = %(action_)s
mail
If you are adding a custom action to an individual jail and there is no existing action property, the jail is currently using the default action. You can change the default higher up in jail.local or you can add the action property to the jail to retain the default:
action = %(known/action)s
your_action_here
Passing Variables into Actions
Sometimes you may want to override variables defined in your actions’ [Init] sections individually per jail. To do this, you can include the variables as comma-separated key=value pairs inside square brackets after an action name.
action = someaction[key1=value1, key2=”value2”, …]
In this example, two variables are passed into the “notifyme” action for the sshd jail:
[sshd]
port = ssh
logpath = %(sshd_log)s
backend = %(sshd_backend)s
action = %(known/action)s
notifyme[token=”ABCDEF123456”, priority=5]
After adding new actions in jail.local, it may not be sufficient to just reload the Fail2Ban daemon, so you should completely restart it:
sudo systemctl restart fail2ban
And check it’s status:
sudo systemctl status fail2ban
And there you have it. Happy banning!
